Features
Linear motorized zoom: 7°~42°
Motorized focus
Linear CMY colour mixing
Linear CTO colour correction
0~100% smooth dimming
Color Wheel: 1 colour wheel with 6 colors plus open
Gobo Wheel: 1 static gobo wheel with 8 gobos plus open, 1 rotating gobo wheel with 6 gobos plus open, easy to replace
Gobo’s outside diameter: 37.3 mm
Gobo’s image diameter: 27 mm
4 facet prism rotating in both directions
Independent frost effect
Motorized linear iris
Various strobe speeds
Weight: 39.5kg
Four fast and smooth framing shutters, each shutter blade position and angle can be controlled individually; Each shutter blade can block out light completely, the framing module can be rotated at ± 45°
Specifications
Light Source: 1 x 600W LED
Colour Temperature: 6500K
Beam Angle: 7°~42°
Luminous Flux: 19000lm
Control
DMX Channel: 30/32 channels
Control Mode: DMX512
Firmware Upgrade: Update via DMX link
Pan/Tilt
Pan/Tilt: 540°/ 270°
Pan/Tilt Resolution: 16 bit
Fixation: Tilt lock
Construction
Display: LCD display
Battery backup for user operation without connecting to the mains
Data In/Out: 3-pin and 5-pin XLR
Power In/Out: PowerCon in
Protection Rating: IP20
www.acme.com.cn
Australian Distributor: ULA group www.ulagroup.com
