The G·7 BeaSt (BeamStrobe) reinvents the moving head concept by implementing two completely different light sources in the same fixture. Its design is based on three major features: a bright throw with full optical control, the ability to expand the beam angle while keeping the light output, and a powerful pixel strobe blinder that boosts the punch.
By combining these three revolutionary solutions, multiple design possibilities appear, including versatile fat-beams, mesmerizing aerial scenes, excellent eye-candy effect, and impressive strobe/pixel/blinder.
Optics
The G-7 BeaSt mounts a special optical system based on multiple reflection collimation over a glass parabolic reflector. This system allows the unit to output a powerful parallel beam of light with a 320mm (11″) lens aperture. The strobe blinder consists in multiple lightsources with individual lenses inserted in the center of the reflector, optimized for direct view applications.
Photometrics
With a beam light output of 50,000 lux at 10 meters, and a strobe blind effect able to reach 50,000 lumen, the G-7 BeaSt offers a performance way above of its size. When the beam and the strobe / blinder are used together, the fixture is able to keep the same lux values with a 10,000 lumen blinder effect.
Aerial FX
The G-7 BeaSt features an unique aerial projection, thanks to its bright parallel beam of light, 6 rotatable gobos, expandable beam throw, and special animation effects. This product has been optimized for high visibility, and therefore it is ideal for long-throws that need to be seen from a distance
TruColor™
SGM uses Full Range Calibration in all LED fixtures over CIE space and black body curve, measured via spectrometer and SGM Illumination Lab software. The consistency of each product and its lifetime expectancy is monitored throught inbuilt sensors to compensate colour shifting and to allow colour temperature re-calibration. To provide the best user experience, SGM’s Color Match procedure ensures accurate wavelength reproduction within the product range via coloured LEDs, dichroic filters, or CMY mixing (depending on the product); all of them specified to match the SGM colour palette.
DryTech™
SGM’s integrated patented Dehumidification process eliminates humidity and breaks down corrosive H2SO4 molecules deriving from polluted air to avoid destructive corrosion. Inbuilt dehumidifiers constantly remove trapped hydrogen from inside of the lighting fixture in a solid estate electrolytic process with no moving parts. The DryTech™ procedure is also based on a Ingress Protection rating of 65 or 66 (depending on the fixture), intended as a full protection against dust and other particles, while ensuring protection against direct water jets.
ThermalDrive™
This thermal management technology provides Advanced Temperature Control monitored via sensors and software, keeping optimal LED junction temperatures, and ensuring maximum reliability for long-term use. SGM’s predictive color mixing algorithm compensates the decay levels of colour-based LEDs for superior colour rendering. Finally, the ThermalDriveTM system includes cutting-edge heat removal via passive thermal techniques and active forced-air cooling (depending on the product), specifically designed to maintain LED efficiency while extending fixture’s lifetime.
