Prolights have just released its latest EclDisplay series, an LED spotlight that sets new standards in lighting technology for galleries, retail, hotels, exhibitions and any high-profile installations.
The fixtures in the EclDisplay range come in a stylish housing, with multiple control options, sources, colours, lenses and accessories, with over 7,000 possible fixture configurations, using the same core technology while meeting different aesthetic or technical requirements.
Define your ideal control
The EclDisplay units are available in three control configurations: DAT, UN and CC. The DAT version comes with a built-in PSU, with manual knob-dimming, RDM, DMX and DALI control on-board. The UN version includes all the above and adds phase-cut dimming for retrofitting in existing systems. The CC (Constant Current) version works with external drivers, allowing installers to complete the light fittings with any track-mounted, rack or boxed drivers, accepting any wired or wireless control (DALI, Casambi, 0-10, on-off).
Select your desired source
The EclDisplay is engineered with a 25W, high CRI LED engine. There are five different source options available: fixed white sources in 2,700K, 3,000K, 4,000K, 5,600K, as well as a 40W RGB+WW source, capable of delivering a wide tuneable white range, as well as beautiful pastels and saturated colours.
Shape the beam to your heart’s content
Prolights has developed optics that unlock the fixtures’ full potential, increasing their efficiency and light output. There are three lenses available: a zoomable 20º – 40º profile lens with 4 lockable blades, allowing to precisely frame any projection area with crisp or soft-edge accents or to project images and textures through the indexable gobo holder.
In addition, the zoom wash optics is available in 15º – 30º and 25º – 50º variants, making it able to spread the light and obtain a wall-washing effect.
Accessories for all applications
The EclDisplay fixtures can be track-mounted, hanged or ceiling recessed through the optional ceiling kit. There is also a wide range of accessories available for the finer details, including a honeycomb louvre, snoot, 4-leaf barndoors, filter-frames and indexable gobo-holders.
Black or white housing, or custom RAL on demand
All fixtures, optics and accessories are stocked in black or white variants, and any custom RAL colour can be produced on request.
prolights.it
Australian Distributor: Show Technology www.showtech.com.au
