Power
- Input Voltage: 100~240V AC, 50/60 Hz
- Power Consumption: 275W
- Connection: Neutrik® PowerCON – In
Photometric
- Light Source: Advanced 6500K 200W White LED Module
- Beam Angle: 7.5° to 40°
- Output: 16,000 lumen, 61,100 lux on @2.5M @7.5°
- PWM: 1200Hz
- LED Lifespan: 60,000 hours
Effects
- Dimming: 0 ~ 100%
- Strobe: 0.5 ~26 Hz
- Focus: Linear via DMX
- Prism: 3-facet & Frost
- Iris: Yes
- Zoom: Linear via DMX 7.5° to 40°
Movement 16 bit Auto Reposition
- Pan: 630°( 4.3 sec) or 540°( 3.9 sec)
- Tilt: 233°(2.2 sec)
Colour
- 8 Colours + Open
Gobos
- Fixed: 1 x 7 + Open Fixed Gobo Wheel
- Rotating: 1 x 7 + Open Interchangeable Rotating Gobo Wheel (Outside Ø27mm, Inside Ø20mm).
Control
- Operational Modes: DMX, Auto Program, Sound Active, Master / Slave
- RDM: Change DMX Address, Display Flip, X/Y Reverse and so on
- Protocol: DMX512 (W-DMX™ Optional)
- DMX Channels: 24 / 25 / 15 / 17
- Interface: 3-Pin & 5-Pin XLR
- Display: 2.4? Colour LCD Control Panel with Back-up Power.
- Software Upgrade via DMX: Yes
Housing
- Materials: ABS & Steel
- Finishing: Matte black
- Cooling: Multi Sensor Thermostat Controlled Variable Speed Fan
- IP rating: IP20
- Dimension: 369 x 402 x 623 mm
- Net Weight: 25 kg
- Rigging: 2pcs Omega Brackets with 1/4-turn Quick Locks
