Specifications
Light Source: 36 x 15W RGBW LED & 49x 0.06W CW LED (6500K)
Beam Angle: 6°
Control
DMX channel: 166/206 channel
Control Mode: DMX512, Art-Net
Firmware Upgrade: Update via DMX link
Pan/Tilt
Pan/Tilt: Infinite
Pan/Tilt Resolution: 16bit
Construction
Display: LCD display
Data In/Out: 3-pin and 5-pin XLR socket,RJ-45
Power socket: Powercon in/out
Protection Rating: IP20
Features
Integrated multi features: beam,wash,pixel effect,star background and moonflower beam…
36 (6×6) x 15W RGBW pixel control LED + 49 (7×7) CW star effect LED
Preset a variety of graphics matrix effect
Outstanding color mixing effect
0~100% smooth dimming,4 optional dimming curves
Adjustable strobe speeds
Excellent thermal control with heat pipe technology
Low noise as the fan speed can be adjusted automatically according to the temperature
Optional reflector mirror module,can create moonflower effect with beam light spotting on the mirror
Electrical and Physical
Power Voltage: AC 100V~240V, 50/60Hz
Power Consumption: 580W
Dimension: 466x246x575mm
Weight: 20Kg
